A Simple Active Directory VM Lab Set Up (Work in Progress)

PreviousPassing the CySA+NextMetasploitable 3 for VMware Workstation

Last updated 2 years ago

Was this helpful?

Active Directory (AD) is a powerful tool used by many organizations to manage their network resources. It provides a centralized location for storing user and computer accounts, as well as permissions for accessing network resources. In this Gitbook post, I will show you how to set up a virtualized AD lab using VMware Workstation. This lab can be a great way to learn about AD and gain hands-on experience with the technology. You can also use this lab to test AD pen-testing techniques.

Overview

Understanding Active Directory and Group Policy

Requirements

VMware Workstation Player 17

Windows 10 Enterprise ISO

Fill out the form then click "Download now"

Click the 64-bit edition to download the Windows 10 Enterprise ISO

Windows 2019 Server ISO

The same steps as downloading Windows 10 Enterprise ISO, fill out the form then download the 64-bit edition of the ISO

Installations

Domain Controller

Launch VMware Workstation Player

Click "Create a New Virtual Machine"

Click "Browse" then open the Windows 2019 Server ISO

Click Next

Input in any name for the "Full name" then click Next

A pop up will say that "You did not enter a Windows product key...", click Yes

Name your virtual machine to anything you want (I named mine as "Domain Controller") then click Next

Select "Split virtual disk into multiple files" then click Next

Uncheck the "Power on this virtual machine after creation" box then click Finish

The Domain Controller virtual machine is now added

Back on VMware Workstation Player home menu, select the domain controller virtual machine and click "Edit virtual machine settings"

Select the Floppy device and click Remove

Select the Memory device and increase the memory to 4 GB (we can change it back to 2 GB after the installation step) then click OK

Now launch the domain controller VM, then quickly press any key once the VM boots up and prompts "Press any key to boot from CD or DVD. ." message. If you missed this step, just exit and relaunch the VM again.

Then click Next, then "Install now"

Select Windows Server 2019 Standard Evaluation (Desktop Experience) for the OS then click Next

Check the "I accept license terms" box then click Next

Select "Custom: Install Windows only (advanced)"

Click "New", then "Apply", then "OK", then finally Next

Now we wait for a bit as the VM is installing the OS, then it will automatically restart and greet us with the "Customize settings" screen

Input any password you want for the Administrator (best to note it down somewhere), then click Finish

The Windows Server VM will tell us to "Press Ctrl + Alt + Delete to unlock"

Click the red boxed icon located at Workstation Player top bar the to send Ctrl+Alt+Del to the VM

Log into the Administrator with the password that you just set earlier

Now we want to get full-screen mode on the Domain Controller VM On the Workstation Player top bar, Click "Player", then "Manage", then "Install VMware Tools..."

In the VM, open the File Explorer and click on "This PC", you will see the VMware Tools is mounted, double-click it to start the installation of VMware Tool

In the installation, click Next, then choose Complete Install and click Next, then click Install, then click Finish

There will be a pop-up that will ask you to restart once the installation is done, click Yes

The VM will restart. Once it booted up, we can toggle full-screen mode for the Domain Controller VM.

Login into Windows, then we're going to rename the computer

Click the Windows icon on the bottom left, then type "View your PC name", then select the option

This will prompt up the About page from the System settings, scroll down a bit, and click Rename this PC

Rename this to "DC" or whatever name you like but make sure the name clearly indicates the machine is a domain controller, then click Next

Windows will ask you to restart, click Restart Now

Once the VM finished restarting, log back into Windows

We will now configure the VM into a Domain Controller

Whenever we login into the Windows Server, the Server Manager is launched

In Server Manager, click Manage, then click Add Roles and Features

Click Next, then choose "Role-based or feature-based installations" for Installation Type, then click Next

Click Next for the Server Selection page, then check the "Active Directory Domain Services" box in the Server Role page, then click Add Features, then click Next

Click Next for the Features page, then click Next for the AD DS page, then click Install for the Results page

Once the installation is done, click Close

On the top bar of the Server Manager, click the Notification icon (the flag), then click "Promote this server to a domain controller"

Select "Add a new forest", then name the root domain as "ADLAB.local" or whatever name you want, then click Next

Set the DSRM password to the same password that you set for the Administrator user earlier, then click Next

Click Next for the DNS Options page, then click Next for the Additional Options page, then click Next for the Paths page, then click Next for the Review Options, then finally click Install for the Prerequisites Check page

The Domain Controller VM will automatically restart once the installation is done

We can check by unlocking the Windows Server login screen and see that we're now part of the ADLAB domain

Domain Machine

Back on the VMware Workstation Player menu, click "Create a New Virtual Machine"

Click "Browse" then open the Windows 10 Enterprise ISO, then click Next

Select Windows 10 Enterprise for the version of Windows to install, then click Next, then click Yes for the pop up about "You did not enter a Windows product key..."

Name your virtual machine to anything you want (I left mine as default) then click Next

Select "Split virtual disk into multiple files" then click Next

Uncheck the "Power on this virtual machine after creation" box then click Finish

Back on VMware Workstation Player home menu, select the Windows 10 virtual machine and click "Edit virtual machine settings"

Similar step to when setting up the Domain Controller VM, select the Floppy device and click Remove, then click OK

Now launch the Windows 10 VM, then quickly press any key once the VM boots up and prompts "Press any key to boot from CD or DVD. ." message. If you missed this step, just exit and relaunch the VM again.

On the Windows Setup page, click Next, then click Install Now

Check the "I accept license terms" box then click Next

Select "Custom: Install Windows only (advanced)"

Click "New", then "Apply", then "OK", then finally Next

The VM will automatically restart and boots up into Windows setup page

On the region select screen, click Yes, then click Yes for the keyboard layout page, then click Skip for the adding second keyboard layout page

On the Sign in with Microsoft page, select "Domain join instead"

Input any name you want for the PC user account name, then click Next

Input any password you want for the account (best to note it down somewhere), then click Next

Input any answer for security questions (I use "tom" for all of the questions), then click Next

Uncheck all the options for the privacy settings page, then click Accept

Click Not Now for the Cortana page if it pops up, then we wait for Windows to finish setting up

Once loaded into Windows, we want to set up full-screen mode for the VM

On the Workstation Player top bar, Click "Player", then "Manage", then "Install VMware Tools..."

Open the File Explorer and click on "This PC", you will see the VMware Tools is mounted, double-click it to start the installation of VMware Tool

In the installation, click Next, then choose Complete Install and click Next, then click Install, then click Finish

A pop-up will ask you to restart the computer, click No

Rename the computer, click the Windows icon on the bottom left, then type "View your PC name", then select the option

This will prompt up the About page from the System settings, click Rename this PC

Rename this PC to "CLIENT01", then click Next

Windows will ask you to restart, click Restart Now, and now you're done with setting up the 1st Domain Machine

Repeat the same above steps for another VM and have the PC renamed to "CLIENT02"

Once done, we now have 1 domain controller and 2 client machines in our virtualized environment

Domain Configuration

Download link:

Download link:

Download link:

📕
https://www.vmware.com/products/workstation-player.html
https://www.microsoft.com/en-us/evalcenter/evaluate-windows-10-enterprise
https://www.microsoft.com/en-us/evalcenter/evaluate-windows-server-2019#Get-started
